Servo Drives for High-Dynamic Drive Systems

Servo Drives by SIEB & MEYER – for Maximum Control Performance and Efficiency


SIEB & MEYER has designed its servo drives for high-dynamic drive applications with the highest requirements in terms of accuracy and control performance. The servo amplifiers offer modern communication interfaces and powerful control technology in a compact system that is ideally suited for high-dynamic applications with quick load changes. Thanks to their high overload capacity and intelligent control technology, the drive controllers by SIEB & MEYER enable extremely precise and reliable motion control.

Opt for state-of-the-art drive technology and maximum efficiency – SIEB & MEYER is the right partner for you.

Servo Drives – Optimally Adapted to Your Requirements



  • Servo Drive SD4S

    Ready for the Future

    Complex tasks are quickly processed with the servo drive SD4S. The devices are designed for stationary use in control cabinets of machine tools, turbo compressors and turbo blowers.

    Servo Drive SD4S

  • Servo Drive SD2B plus

    Frequenzumrichter SD2B plus

    The Space Marvel

    The special compact design of servo drive SD2B plus allows easy and flexible integration of the device. The IP20 housing convinces with its reduced construction height of only 25 mm.

    Servo Drive SD2B plus

  • Servo Drive SD2S

    The Multitalent

    Powerful, flexible, compact – these words describe the SIEB & MEYER servo drives SD2S regarding high-speed applications.

    Servo Drive SD2S

  • Drive Controller SD2

    The Team Player

    The digital drive controller SD2 can be connected to your controller via the real-time bus SERVOLINK 4 using fiber optic cables. This design allows a direct and fast access to all relevant drive parameters.

    Drive Controller SD2

Servo Drives by SIEB & MEYER - an Overview



Device series Power range Input voltage Motion Controller Communication Feedback system Operating mode  Type Safety function
SD2B plus ... 0.8 kVA 24 .. 80 VDC no RS232, CAN Bus, via Gateway: Profibus , Profinet , EtherCAT TTL, Biss C Speed -, torque operation, interpolated position control Single-axis unit with external DC supply STO
SD2 1 .. 80 kVA 230 .. 480 VAC no RS485, via Gateway: Profibus , Profinet , EtherCAT Resolver, Linear Hall, EnDat 2.1, TTL, 1Vss Speed -, torque operation, interpolated position control Multi-axis system with central power supply unit STO
SD2S  0.3 .. 55 kVA 115 .. 480 VAC no CAN Bus, EtherCAT, via Gateway: Profibus , Profinet Resolver, Linear Hall, EnDat 2.1, TTL, 1Vss Speed -, torque operation, interpolated position control Single-axis device STO
SD4S 0.8 .. 66 kVA 115 .. 480 VAC no CANopen, EtherCAT, (Profinet Powerlink) TTL, Biss C, Endat 2.2 Speed, torque operation, positioning Single-axis device STO
Customized Benefit from our longtime know-how!
From the project planning phase to serial production – you get everything from a single source at fast, adjustable and at economically viable conditions.

Control systems & drive technology – customized for your application

With our experience from customized drive systems that are meanwhile produced in large series and as well as our standard devices, we are supporting you from the project planning phase to the series production.
