 SPECIAL PURPOSE MACHINES

THE OPTIMAL PRODUCTS FOR SPECIAL PURPOSE MACHINES

In the field of special purpose machines, servo-driven systems are key components to further increase the degree of automation. The advantages include a more flexible process design and the opportunity to implement a more accurate process monitoring and documentation.

Servo amplifiers by SIEB & MEYER enable the required high-dynamic operation of servo motors. In addition, the devices provide application-specific interfaces and functions that make the development of the according system easier. A special advantage arises in applications with more than one axis: The SD2 series, for example, is designed as multi-axis system and therefore suitable for these applications.

Compared to devices with individual power supply units, this saves a considerable amount of energy. Another very important factor for the special purpose machine construction is the development competence: thanks to the flexibility and the expertise of SIEB & MEYER, an individual solution will be found for every challenge.

PRODUCT OVERVIEW



Device series Power range Input voltage Motion Controller Communication Feedback system Operating mode Type Safety functions
SD2 1 .. 80 kVA 230 .. 480 VAC no RS485, via Gateway: Profibus, Profinet, EtherCAT Resolver, Linear Hall, EnDat 2.1, TTL, 1Vss Speed, torque operation, interpolated position control Multi-axis system with central power supply unit STO, SLOF, SFM
SD2S 0.3 .. 55 kVA 115 .. 480 VAC no CAN Bus, EtherCAT via Gateway, Profibus, Profinet Resolver, Linear Hall, EnDat 2.1, TTL, 1Vss Speed, torque operation, interpolated position control Single-axis device STO
SD3 1.5 .. 55 kVA 115 .. 480 VAC Integrated, C/C++, IEC61131 CAN Bus, EtherCAT, OPC UA Resolver Linear Hall, EnDat 2.1, Hyperface DSL Speed, torque operation, positioning, sequence control Single-axis device STO
Customized

Benefit from our longtime know-how!
From the project planning phase to serial production – you get everything from a single source at fast, adjustable and economically viable conditions.

  • Servo Amplifier SD3

    THE GENIUS

    With the servo amplifier SD3 SIEB & MEYER offers a solution for complex drive tasks, e.g. for high-dynamic positioning applications or fastening and press applications operated by servo motors.



  • Drive System SD2

    THE TEAM PLAYER

    The digital drive system SD2 can be connected to your controller via the real-time bus SERVOLINK 4 using fiber optic cables. This design allows a direct and fast access to all relevant drive parameters.



PRODUCTS PRECISELY TAILORED FOR YOUR APPLICATION

With our experience from customized drive systems that are meanwhile produced in large series and as well as our standard devices, we are supporting you from the project planning phase to the series production.
