Printed Circuit Board Scoring

The optimal products for your PCB scoring machine

PCB scoring is determined by the continuously increasing technical and commercial requirements of the electronics industry. The prevailing pricing pressure on electronic devices demands a step-up in productivity by means of an increasing machine automation.

In addition, gathering process data ensures a rising process reliability. The CNC controls by SIEB & MEYER contribute to meet these challenges with your machine not only today, but also in the future.

Product Overview


Variation Description Drive package
PCD36 Complete hardware and software solution for the operation of a PCB scoring machine SD2 and SD2S as the basis for the operation of servo amplifiers and frequency converters
Variation Power range Input voltage Motion Controller Communication Feedback system Operating mode Version
SD2 1 .. 80 kVA 230 .. 480 VAC no RS485, SERVOLINK, via Gateway: Profibus, Profinet, EtherCAT Resolver, Linear-Hall, EnDat2.1, TTL, 1Vss Speed -, torque operation interpolated position control Multi-axis system with central power supply unit
SD2S 0.3 .. 55 kVA 115 .. 480 VAC no CAN Bus, EtherCAT, SERVOLINK, via Gateway: Profibus, Profinet Resolver, Linear-Hall, EnDat2.1, TTL, 1Vss Speed -, torque operation interpolated position control Single-axis device
  • PCD 36

    Complete Drive System for Scoring Applications

    The machine control PCD36 is specially designed for the operation of modern scoring machines used for processing printed circuit boards.


  • Drive System SD2

    The Team Player

    The digital drive system SD2 can be connected to your controller via the real-time bus SERVOLINK 4 using fiber optic cables. This design allows a direct and fast access to all relevant drive parameters.

Products precisely tailored for your application

With our experience from customized drive systems that are meanwhile produced in large series and as well as our standard devices, we are supporting you from the project planning phase to the series production.
